BMW 4 Series Coupé (G22), technical data

THE 4

THE BMW 4 SERIES COUPÉ: ENGINES & TECHNICAL DATA

Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW 4 Series Coupé.

Read more
THE 4 THE BMW 4 SERIES COUPÉ: ENGINES & TECHNICAL DATA
BMW 4 Series Coupé

TECHNICAL DATA OF THE BMW 4 SERIES COUPÉ.

Select model

Weight

Unladen weight EU in kg 1,600
Max. permissible weight in kg 2,015
Permitted load in kg 490
Permitted axle load front/rear in kg 970/1,120
Luggage capacity min. (seats up or roof down) in l 440
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 240
Acceleration 0–100 km/h in s 7.5

Fuel consumption

Urban in l/100 km 7.6
Extra-urban in l/100 km 5.7
Combined in l/100 km 6.4
CO2 combined emissions in g/km 146
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,665
Max. permissible weight in kg 2,080
Permitted load in kg 490
Permitted axle load front/rear in kg 1,020/1,130
Luggage capacity min. (seats up or roof down) in l 440
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 96.4/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 238
Acceleration 0–100 km/h in s 7.8

Fuel consumption

Urban in l/100 km 8.0
Extra-urban in l/100 km 6.2
Combined in l/100 km 6.9
CO2 combined emissions in g/km 157
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,620
Max. permissible weight in kg 2,030
Permitted load in kg 485
Permitted axle load front/rear in kg 980/1,120
Luggage capacity min. (seats up or roof down) in l 440
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 180-190 (245-258)/4,500-6,500 - 5,000-6,500
Engine torque (Nm) at 1/min 400/1,550-4,400 - 1,600-4,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.9-5.8

Fuel consumption

Urban in l/100 km 8.0
Extra-urban in l/100 km 5.8
Combined in l/100 km 6.6
CO2 combined emissions in g/km 151
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,680
Max. permissible weight in kg 2,095
Permitted load in kg 490
Permitted axle load front/rear in kg 1,030/1,130
Luggage capacity min. (seats up or roof down) in l 440
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 96.4/82.0
Engine power in kW (hp) at 1/min 180-190 (245-258)/4,500-6,500 - 5,000-6,500
Engine torque (Nm) at 1/min 400/1,550-4,400 - 1,600-4,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.7-5.6

Fuel consumption

Urban in l/100 km 8.3
Extra-urban in l/100 km 6.2
Combined in l/100 km 7.0
CO2 combined emissions in g/km 159
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,770
Max. permissible weight in kg 2,190
Permitted load in kg 495
Permitted axle load front/rear in kg 1,070/1,180
Luggage capacity min. (seats up or roof down) in l 440
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2.998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 275-285 (374-387)/5,500-6,500 - 5,800-6,500
Engine torque (Nm) at 1/min 500/1,800-5,000 - 1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.8

Fuel consumption

Urban in l/100 km 9.8
Extra-urban in l/100 km 6.4
Combined in l/100 km 7.7
CO2 combined emissions in g/km 174
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1.815
Max. permissible weight in kg 2,245
Permitted load in kg 505
Permitted axle load front/rear in kg 1,110/1,190
Luggage capacity min. (seats up or roof down) in l 440
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2.998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 275-285 (374-387)/5,500-6,500 - 5,800-6,500
Engine torque (Nm) at 1/min 500/1,800-5,000 - 1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.5

Fuel consumption

Urban in l/100 km 10.1
Extra-urban in l/100 km 6.4
Combined in l/100 km 7.8
CO2 combined emissions in g/km 178
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy
Including of /content/bmw/marketHK/bmwhk_com/en_HK/publicPools/teaser-pool/medium-teasers/tyre-energy-lables/jcr:content/par-4col/wideteaser_67 failed

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW M440i xDrive Coupé:
Fuel consumption in l/100 km (combined): 8.5–8.0
CO2 emissions in g/km (combined): 194–181



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more
​

Fuel consumption and CO2 emissions.

  • BMW M440i xDrive Coupé:
    Fuel consumption in l/100 km (combined): 7.8
    CO2 emissions in g/km (combined): 178

    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
