BMW 1 SERIES: ENGINES & TECHNICAL DATA

Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW 1 Series.

Read more
THE 1BMW 1 SERIES: ENGINES & TECHNICAL DATA

BMW 1 SERIES: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1,365 [1,395]
Max. permissible weight in kg 1,845 [1,870]
Permitted load in kg 555 [550]
Permitted axle load front/rear in kg 980/940 [1,005/940]
Luggage capacity min. (seats up or roof down) in l 380 [380]
Luggage capacity max. (seats down or roof up) in l 1,200 [1,200]
Trailer load 8% (braked) in kg 1,300 [1,300]
Trailer load 12% (braked) in kg 1,300 [1,300]
Trailer load (unbraked) in kg 680 [695]

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 100-103 (136-140)/4,500-6,500
Engine torque (Nm) at 1/min 220/1,480-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 211 [211]
Acceleration 0–100 km/h in s 8.5 [8.5]

Fuel consumption

Urban in l/100 km 7.9 [7.0]
Extra–urban in l/100 km 5.3 [5.3]
Combined in l/100 km 6.3 [5.9]
CO2 combined emissions in g/km 143 [135]
Tank capacity, approx. in l 42

Wheels

Tyre dimensions front 205/55 R16 91 W
Tyre dimensions rear 205/55 R16 91 W
Wheel dimensions and material front 7 J x 16 inches, light-alloy
Wheel dimensions and material rear 7 J x 16 inches, light-alloy

Weight

Unladen weight EU in kg 1,465
Max. permissible weight in kg 1,920
Permitted load in kg 530
Permitted axle load front/rear in kg 1,035/955
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load 8% (braked) in kg 1,300
Trailer load 12% (braked) in kg 1,300
Trailer load (unbraked) in kg 730

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 131-141 (178-192)/5,000-6,000
Engine torque (Nm) at 1/min 280/1,350-4,600
Compression ratio : 1 11.0

Performance

Top speed in km/h 235
Acceleration 0–100 km/h in s 7.0

Fuel consumption

Urban in l/100 km 7.9
Extra–urban in l/100 km 5.5
Combined in l/100 km 6.4
CO2 combined emissions in g/km 147-146
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/45 R17 94 Y XL
Tyre dimensions rear 225/45 R17 94 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,515
Max. permissible weight in kg 2,000
Permitted load in kg 560
Permitted axle load front/rear in kg 1,085/990
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -
Trailer load (unbraked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 180 (245)/5,000-6,500
Engine torque (Nm) at 1/min 380/1,500-4,400
Compression ratio : 1 10.2

Performance

Top speed in km/h 243
Acceleration 0–100 km/h in s 6.3

Fuel consumption

Urban in l/100 km 8.4
Extra–urban in l/100 km 5.9
Combined in l/100 km 6.8
CO2 combined emissions in g/km 156
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/40 R18 92 Y XL
Tyre dimensions rear 225/40 R18 92 Y XL
Wheel dimensions and material front 8 J x 18 inches, light-alloy
Wheel dimensions and material rear 8 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1,600
Max. permissible weight in kg 2.085
Permitted load in kg 560
Permitted axle load front/rear in kg 1,120/1,020
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1,200
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -
Trailer load (unbraked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 225 (306)/5,000-6,250
Engine torque (Nm) at 1/min 450/1,750-4,500
Compression ratio : 1 9.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.8

Fuel consumption

Urban in l/100 km 9.1
Extra–urban in l/100 km 6.5
Combined in l/100 km 7.4
CO2 combined emissions in g/km 170
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/40 R18 92 Y XL
Tyre dimensions rear 225/40 R18 92 Y XL
Wheel dimensions and material front 8 J x 18 inches, light-alloy
Wheel dimensions and material rear 8 J x 18 inches, light-alloy
Including of /content/bmw/marketHK/bmwhk_com/en_HK/publicPools/teaser-pool/medium-teasers/tyre-energy-lables/jcr:content/par-4col/wideteaser_67 failed

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW M135i xDrive:
Fuel consumption in l/100 km (combined): 7.9–7.4
CO2 emissions in g/km (combined): 178–167



BMW 128ti:
Fuel consumption in l/100 km (combined): 7.5–6.8
CO2 emissions in g/km (combined): 178–168

Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
